FBT MS-F210 Flybar
The FBT MS-F210 is a versatile professional rigging accessory that serves as both a flying bar for suspended arrays and a sturdy metal base for ground-stacked configurations. Engineered for high-capacity deployments, it can support a vertical cluster of up to 16 speakers or a ground stack of up to 6 modules.
Key Features
- Dual-Purpose Design: Functions as a primary suspension point for flown systems or a secure foundation for ground stacks.
- Broad Compatibility: Optimized for the MUSE Series (210L, 218S, 118FS) and HORIZON VHA Series.
- Precision Rigging: Integrated connecting flanges allow for precise splay angle adjustments between 0° and 10° in 1° increments.
- Safety Certified: Constructed from heavy-duty steel and manufactured entirely in Italy to meet rigorous professional standards.
Technical Specifications
| Feature | Specification |
|---|---|
| Product Code | 38834 |
| Material | Steel |
| Net Dimensions (WxHxD) | 686 x 100 x 652 mm (27 x 3.93 x 25.66 in) |
| Transport Dimensions | 740 x 125 x 730 mm (29.13 x 4.92 x 28.74 in) |
| Net Weight | 30 kg / 66.13 lb |
| Transport Weight | 33.50 kg / 73.85 lb |
Safety Requirements
- Qualified Personnel Only: Installation must be performed exclusively by qualified technicians in compliance with local safety standards.
- Secondary Safety: All suspended systems must be equipped with an independent secondary safety system of adequate load capacity.
- Weight Verification: Ensure the supporting structure can bear the combined weight of the speakers and all rigging accessories.
- Inspection Schedule: Regular, specific inspections of all components are mandatory for long-term system safety.
